Typical Specification

1. Rating: DC12v 10mA
2. Free Position: 3.7±0.2mm
3. Operating Position: 3.3±0.3mm
4. Contact resistance: 100MΩ max
5. Insulation resistance: 100MΩ min
6. Operating life: 50,000 cycles
